Check j1939 circuit resistance at the ecu.

J1939 to obc wiring diagram. There may be a problem in the j1939 wiring between the ecu and the j1939 backbone. A mating connector and terminals are supplied to make the connection to the vehicle j1939 connection. Check wiring diagram for your vehicle. If the result is 60 ω the ecu is probably at fault.

Nine pin diagnostic a ground b power c j1939 data. Further these higher layer protocols will increasingly be based on the next generation of can can fd e g. Some peterbilt vehicles do not use c and d for j1939. Proper voltage ground and j1939 h1939 voltage.

Dg technologies product pinouts and industry connectors reference guide page 4 of 38 copyright 2012 2014 dearborn group inc. Can bus and sae j1939 wiring requirements and trouble shooting posted by wilfried voss on may 10 2017 controller area network can is a serial network technology that was originally designed for the automotive industry especially for european cars but has also become a popular bus in industrial automation as well as other applications. Transmissions will either be j1708 j1587 or j1939 depending on the model year of the coach. All ecus fail to respond.

Checking continuity and bandwidth of j1939 h1939 continuity and bandwidth tests should be conducted with all modules and 120ohm terminating resistors removed install a jumper wire across both legs of the network similar to the diagram below. 8 0 according to 8 reports in our database 8 positive and 0 negative this pinout should be correct. The j1939 datalink polarity may be reversed at the diagnostic connector. Connect one end of the harness into the trcm harness plug labeled vehicle can.

J1939 data will require the data c wire pair and a 9 pin diagnostic plug. Can connection harness tid31015 is provided for connection to j1939. Some of the most common standards include sae j1939 obd2 and canopen. 1 0 according to 1 reports in our database 1 positive and 0 negative this pinout should be correct.

Dg technologies 33604 west 8 mile. If the result is not 60 ω check and repair j1939 datalink wiring. Obd 2 universal diagnostic serial cable scheme for iso 15765 4 can sae j1850 pwm sae j1850 vpw iso 9141 2 iso 14230 4 and sae j1939 pinout status.
